SHR150 Specification Sheet
AFM Probe Type: SHR150
-
Call us: + 49 (0) 6441 870 6272 Wetzlar, Germany
- + 49 (0) 6 441 870 6 272
- + 49 (0) 6 441 870 6 274
- info@nanoandmore.com
- close
View this product on
manufacturer's website
manufacturer's website
Learn more about this and other AFM Tips
Learn more about this and other AFM Cantilevers
Order this product
Print spec sheetProduct Description:
Single carbon spike on silicon apex!
Based on BudgetSensors' well established Tap150-G probe
The SHR-150 probe has a single hydrophobic diamond-like carbon extratip at the apex of Gold coated silicon etched probe. There are no additional smaller extratips near the main one, just one well defined extratip. The SHR-150 can be used even for imaging of rough surfaces - there will not be repeated features in the scan due to tip artefacts from extratips with different length and angle.
This product features alignment grooves on the backside of the holder chip.
AFM Probe Specifications:
AFM Cantilever(s):
| cant. | shape | length | width | thickness | force const. | res. freq. | probe base |
|---|---|---|---|---|---|---|---|
| beam | 124 µm (115 - 135 µm)* | 25 µm (20 - 30 µm)* | 2.1 µm (1.1 - 3.1 µm)* | 5 N/m (1.5 - 15 N/m)* | 150 kHz (75 - 225 kHz)* | ||
AFM Tips:
| cant. | shape | tip height | tip set back | tip radius | full cone angle | half cone angle | |
|---|---|---|---|---|---|---|---|
| Rotated, Supersharp, Custom |
17 µm (15 - 19 µm)* | 15 - 19 µm* | 15 µm (10 - 20 µm)* |
20°-25° along cantilever axis |
* typical range
Coating:
70nm Gold on both sides of the cantilever. Carbon spike not coated!Purchasing Information
Product Availability:
Special development, on demand
Price Description:
Does not include VAT or customs duties.
Payment within 30 days from date of invoice, no discount. Payment free of bank chargesTerms & Conditions:
your basket is EMPTY
Order:
| Order Code | Probes per Set | price, EUR | Quantity |
|---|---|---|---|
| SHR150-5 | 5 pcs | 365.00 |
|
| SHR150-15 | 15 pcs | 820.00 |
|
