AFM Probes  »
 Order
 Request a quote (RFQ)
Order Code / Price*
Quantity
Tap300Al-G-10 Box of 10 AFM Probes
205.00 EUR
Tap300Al-G-380 Box of 380 AFM Probes
4500.00 EUR
Your volume discount is 3290.00 EUR or 42.20%
Product availability: On stock

Tap300Al-G

best bang for your buck

Standard Tapping Mode AFM Probe

Manufacturer: BudgetSensors

Coating: Reflective Aluminum
AFM tip shape: Rotated
AFM Cantilever
F 300 kHz
C 40 N/m
L 125 µm
*nominal values
Applications
How to optimize AFM scan parameters gear icon

Micromachined monolithic silicon AFM probe for high frequency non-contact and tapping mode operation.

The consistent AFM tip radius of less than 10 nm ensures high resolution and good reproducibility. The rotated AFM tip provides more symmetric representation of high sample features.

The AFM probe features a reflective aluminum coating on the back side of the AFM cantilever. For measurements in liquids please use the back side gold coated Tap300GD-G or the overall gold coated Tap300GB-G!

With its industry standard dimensions of 3.4 x 1.6 x 0.3 mm the holder chip fits most commercial AFM systems.

Consistent high quality at a lower price!

This AFM probe features alignment grooves on the back side of the holder chip.

Aluminium reflex coating on detector side of the cantilever, 30 nm thick
AFM Tip:

  • AFM Cantilever:
  • Beam
  • 40 N/m (20 - 75 N/m)*
  • 300 kHz (200 - 400 kHz)*
  • 125 µm (115 - 135 µm)*
  • 30 µm (25 - 35 µm)*
  • 4 µm ( 3 - 5 µm)*
  • * typical range
