500 µm Thick AFM Support Chips

PNP-DB

Silicon Nitride AFM Probe

Coating: Reflective Gold
Tip Shape: Pyramid

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.48 N/m

0.06 N/m

L

100 µm

200 µm

The Standard Silicon Nitride AFM probe

PNP-TR

Silicon Nitride AFM Probe

Coating: Reflective Gold
Tip Shape: Pyramid

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

top value

XNC12/Cr-Au BS

AFM Probe with 2 Different Gold Coated Silicon Nitride AFM Cantilevers

Coating: Reflective Gold
Tip Shape: Pyramid

AFM Cantilevers: 2

1

2

F

17 kHz

67 kHz

C

0.08 N/m

0.32 N/m

L

200 µm

100 µm

PNP-TRS

Silicon Nitride AFM Probe Single Cantilever Compatible with ScanAsyst®** Mode

Coating: Reflective Gold
Tip Shape: Pyramid

AFM Cantilever:

F

67 kHz

C

0.32 N/m

L

100 µm

best bang for your buck

SiNi

Silicon Nitride AFM Probe with 2 Different AFM Cantilevers on Each Side of the Chip

Coating: Reflective Gold
Tip Shape: Pyramid

AFM Cantilevers: 4

1

2

F

30 kHz

10 kHz

C

0.27 N/m

0.06 N/m

L

100 µm

200 µm

BudgetComboBox

Mixed Box with 50 BudgetSensors AFM probes of your choice

Coating: various
Tip Shape: various

PNP-TR-Au

Gold Coated Silicon Nitride AFM Probe

Coating: Gold Overall
Tip Shape: Pyramid

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

XNC12/Cr-Au

AFM Probe with 2 Different Gold Coated Silicon Nitride AFM Cantilevers

Coating: Gold Overall
Tip Shape: Pyramid

AFM Cantilevers: 2

1

2

F

17 kHz

67 kHz

C

0.08 N/m

0.32 N/m

L

200 µm

100 µm

Mix and Match Box

Mixed box: up to 400 MikroMasch AFM probes

Coating: various
Tip Shape: various

PNP-TR-TL

Tipless Silicon Nitride AFM Cantilever

Coating: Reflective Gold
Tip Shape: Tipless

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

PNP-TR-TL-Au

Tipless, Gold Coated Silicon Nitride AFM Cantilever

Coating: Gold Overall
Tip Shape: Tipless

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

CP-PNP-Au

Colloidal AFM probe, AFM cantilever with round AFM tip like a ball

Coating: Reflective Gold
Tip Shape: Sphere, Gold
Sphere Diameter: 1.5 - 9 µm

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

CP-PNP-SiO

Colloidal AFM probe, AFM cantilever with round AFM tip like a ball

Coating: Reflective Gold
Tip Shape: Sphere, Silicon Dioxide
Sphere Diameter: 1.98 - 14.45 µm

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

CP-PNP-BSG

Colloidal AFM probe, AFM cantilever with round AFM tip like a ball

Coating: Reflective Gold
Tip Shape: Sphere, Borosilicate Glass
Sphere Diameter: 5 - 20 µm

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

CP-PNP-PM

Colloidal AFM probe, AFM cantilever with round AFM tip like a ball

Coating: Reflective Gold
Tip Shape: Sphere, PMMA
Sphere Diameter: 1.5 - 14.59 µm

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm

CP-PNP-PS

Colloidal AFM probe, AFM cantilever with round AFM tip like a ball

Coating: Reflective Gold
Tip Shape: Sphere, Polystyrene
Sphere Diameter: 1.98 - 14.45 µm

AFM Cantilevers: 2

1

2

F

67 kHz

17 kHz

C

0.32 N/m

0.08 N/m

L

100 µm

200 µm
